Ultrasound Level Sensor
UD485
Built-in cloud server, SMS alert system, and data report center.
With its advanced all-in-one design and dual-network architecture,
this system offers continuous temperature monitoring and
alert functions. Specially designed for medical facilities and vaccine storage,
it effectively addresses issues in traditional monitoring systems,
ensuring safe and reliable temperature management.
– Application areas –
Medical refrigerators, vaccine storage, blood banks,
cold storage, refrigerated vehicles, temperature alert systems
Download
Center
Feature of Product
Optional Code & Specifications
UD485
Code
1
| Code 1 | Line length |
|---|---|
| N | 10m |
| C | 10m + quick connector |
| Code 1 | Detection Range |
|---|---|
| N | 10 m |
| C | 10 m + quick connector |
| Range | 0.4 – 12 m (40kHz) |
|---|---|
| Accuracy | 0.5% |
| Voltage | 10VDC~28VDC |
| Power | ≤50mA (max.1W) |
| Output | RS485, Standard Modbus |
| Op.Temp. | -20~60°C |
| St.Temp. | -40～80°C |
| Pressure | 1 Standard Atmospheric |
| Protection | IP68 |
| Weight | ≤1000g |
| Housing | ABS |
| Probe | ABS |
| Cable | Standard 10m |
| Measuring Range | 0.4 – 12 m (40kHz) |
|---|---|
| Accuracy | 0.5% |
| Voltage | 10VDC~28VDC |
| Power | ≤50mA (max.1W) |
| Output | RS485, Standard Modbus |
| Op.Temp. | -20~60°C |
| St.Temp. | -40～80°C |
| Pressure | 1 Standard Atmospheric |
| Protection | IP68 |
| Weight | ≤1000g |
| Housing | ABS |
| Probe | ABS |
| Cable | Standard 10m |
