IoT Smart Power Analysis System
MPS
‧ Suitable for various applications that require electrical power monitoring.
‧ Semi-portable design, allowing flexible installation or addition of a handle as needed.
‧ Capable of measuring multiple electrical parameters for accurate power quality and operational diagnostics.
‧ Report output function enables convenient organization and analysis of historical power data.
–Application areas–
Energy management, factories, buildings, and equipment power monitoring.
Download
Center
Feature of Product
Optional Code & Specifications
MPS
Code
1
Code
2
Code
3
| Code 1 | Connector | Code 2 | Checklist Specifications | Code 3 | SIM Card Communication |
|---|---|---|---|---|---|
| N | Cable gland (Fixed) | N | None | N | None |
| 200 | ø24mm 200A CT | ||||
| C |
Quick connector (portable, with handle) |
500 | ø36mm 500A CT | 4G |
4G communication (built-in antenna) |
| 1000R | Rogowski coil 1000A | 4GO | 4G communication (external antenna) |
| Code 1 | Connector | Code 2 | Checklist Specifications |
|---|---|---|---|
| N | Cable gland (Fixed) | N | None |
| 200 | ø24mm 200A CT | ||
| C | Quick connector (portable, with handle) | 500 | ø36mm 500A CT |
| 1000R | Rogowski coil 1000A |
| Code 3 | SIM Card Communication |
|---|---|
| N | None |
| 4G | 4G communication (built-in antenna) |
| 4GO | 4G communication (external antenna) |
| Power | AC Input : DC85~275V | ||
|---|---|---|---|
| Power Consumption : ≦2W/10VA | |||
| Operating Temperature | -25~55°C | Storage Temperature | -40~70°C |
| Rated Voltage | AC 0~500V | Rate | Single tariff |
| AC withstand Voltage | 4KV for 1 minute | Pulse Withstand Voltage | 6KV-1.2uS |
| Rated Current | 5A CT input | Working Current | 0.4%lb-lmax |
| Short-term Overcurrent | 20 Imax for 0.01s | Working Frequency | 50 or 60HZ |
| Maximum Reading Value | 9999999.9kWh/kVarh | Voltage and Current | 0.5% |
| Power Factor | 0.01 | Frequency | 0.2% |
| Active Power | ±0.5% | Reactive Power | ±0.5% |
| Material | ABS | Installation Type | Aluminum Rail |
| Communication Method | RS-485 Modbus RTU | International Standards | IEC62053-21 / EN50470-1/3 |
| Dimensions | 300x400x190 mm | Weight | <5kg |
| IP Rating | IP67 | ||
| Calibration | Class 0.5 calibration, TAF 0061 / TAF 1733 accredited | ||
| Certification | CE (EU) and FCC (US) certified | ||
| Power | AC Input : DC85~275V |
|---|---|
| Power Consumption : ≦2W/10VA | |
| Operating Temperature | -25~55°C |
| Storage Temperature | -40~70°C |
| Rated Voltage | AC 0~500V |
| Rate | Single tariff |
| AC withstand Voltage | 4KV for 1 minute |
| Pulse Withstand Voltage | 6KV-1.2uS |
| Rated Current | 5A CT input |
| Working Current | 0.4%lb-lmax |
| Short-term Overcurrent | 20 Imax for 0.01s |
| Working Frequency | 50 or 60HZ |
| Maximum Reading Value | 9999999.9kWh/kVarh |
| Voltage and Current | 0.5% |
| Power Factor | 0.01 |
| Frequency | 0.2% |
| Active Power | ±0.5% |
| Reactive Power | ±0.5% |
| Material | ABS |
| Installation Type | Aluminum Rail |
| Communication Method | RS-485 Modbus RTU |
| International Standards | IEC62053-21 / EN50470-1/3 |
| Dimensions | 300x400x190 mm |
| Weight | <5kg |
| IP Rating | IP67 |
| Calibration | Class 0.5 calibration, TAF 0061 / TAF 1733 accredited |
| Certification | CE (EU) and FCC (US) certified |
